Aruba ION 1930 24-Port Gigabit PoE Switch

Aruba ION 1930 24-Port Gigabit PoE Switch with 4x 10GbE SFP+ Uplinks | 195W Class 4 PoE | 128 Gbps Switching | 95.23 Mpps Throughput | ARM Cortex-A9 | Cloud/Web/SNMP Management - Image 2

Aruba ION 1930 24-Port Gigabit PoE Switch with 4x 10GbE SFP+ Uplinks | 195W Class 4 PoE | 128 Gbps Switching | 95.23 Mpps Throughput | ARM Cortex-A9 | Cloud/Web/SNMP Management

Original price was: ₹98,499.00.Current price is: ₹49,249.00. Inc. tax (₹41,736.44Exc. Tax)

The Aruba ION 1930 24-Port Gigabit PoE Switch is an advanced Layer 2+ smart-managed switch equipped with 24x PoE-enabled Gigabit ports and 4x high-speed 10GbE SFP+ uplinks. With 195W of Class 4 PoE, 128 Gbps switching capacity, and a fanless design, it’s perfect for SMBs requiring silent, powerful performance for powering APs, IP phones, and more.

Add to compare

Pick up from the FGTECH Store

To pick up today

0-1 Days

Free

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Free

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGIN7MU66SKY Categories: Networking Devices, PoE Switches

Description

The Aruba ION 1930 24-Port Gigabit PoE Switch is designed for small businesses seeking robust performance, smart management, and integrated PoE in a quiet, efficient design. Aruba ION 1930 24-Port Gigabit PoE Switch comes with 24 autosensing Gigabit ports with Class 4 PoE (up to 30W per port) and 4 SFP+ 10GbE uplinks, Aruba ION 1930 24-Port Gigabit PoE Switch is perfect for powering and connecting modern devices like access points, security cameras, and VoIP phones—all while maintaining fast backbone or inter-switch connectivity.

Aruba ION 1930 24-Port Gigabit PoE Switch is delivering 195W of PoE power and 128 Gbps of switching capacity, it supports high-throughput workloads in demanding environments like tech offices, healthcare, hospitality, and retail. With a fanless design, it ensures silent operation even when deployed in noise-sensitive locations.

Setup and management are simplified via the Aruba Instant On Cloud portal, mobile app, local web GUI, or SNMP, making this a flexible choice for both novice and experienced administrators. It also includes advanced features such as VLANs, IGMP snooping, QoS, link aggregation, and loop protection.

Aruba ION 1930 24-Port Gigabit PoE Switch is built with an ARM Cortex-A9 800 MHz processor, 512 MB SDRAM, and 256 MB flash, this switch is engineered for enterprise-grade stability and uptime.

Key Features

✅ 24x 10/100/1000 Mbps PoE+ Ports – Power your access points, VoIP phones, IP cameras & more
✅ 4x SFP+ 1/10GbE Uplinks – Ultra-fast uplinks for fiber connections and aggregation
✅ 195W Class 4 PoE Budget – Ample power across connected PoE devices
✅ 128 Gbps Switching Capacity – Designed for bandwidth-heavy business environments
✅ 95.23 Mpps Throughput – Smooth performance during peak data usage
✅ Smart-Managed via Cloud/Web/SNMP – Intuitive management using Instant On portal, app, or GUI
✅ Fanless Silent Design – Ideal for quiet spaces like retail, hospitality, or offices

Product Details

Core Specifications

Category	Details
Model Number	1930-24G-PoE+-4SFP+ (195W)
Switch Type	Smart Managed Layer 2 Gigabit Ethernet
Copper Ports	24 x RJ-45 10/100/1000 (PoE+)
Fiber Uplinks	4 x SFP+ (1/10GbE)
PoE Standard	IEEE 802.3af/at (Class 4)
Total PoE Budget	195W
Form Factor	1U rack-mountable

Performance Metrics

Category	Details
Switching Capacity	128 Gbps
Throughput	95.23 Mpps
Packet Buffer	1.5 MB
Processor	ARM Cortex-A9 @ 800MHz
Memory	512MB SDRAM + 256MB Flash

Power Specifications

Category	Details
Power Consumption	Max: 280W │ Idle: 30W
Input Voltage	100-127VAC or 200-240VAC
PoE Port Configuration	All 24 ports support PoE+
Max PoE Per Port	30W (802.3at)

Physical Dimensions

Unit	Height	Width	Depth	Weight
Imperial	1.73 in	17.42 in	10.42 in	7.69 lb
Metric	4.39 cm	44.25 cm	26.47 cm	3.49 kg

Key Features

Feature	Benefit
High-Power PoE+	Powers up to 24 PoE+ devices (195W total)
10G Uplink Ready	Quad SFP+ ports support future 10G upgrades
Cloud-Managed PoE	Remote power monitoring and scheduling
Enterprise Performance	128Gbps switching capacity for demanding applications

PoE Capabilities

Parameter	Specification
PoE Standards	IEEE 802.3af (15.4W) / 802.3at (30W)
Total Budget	195W (allocated automatically)
Port Priority	Configurable power prioritization
Supported Devices	IP phones, cameras, APs, IoT devices (up to 24 simultaneously)

Management & Security

Category	Details
Management Options	Instant On Portal, Web GUI, SNMP
PoE Controls	Per-port enable/disable, power monitoring
Security Features	802.1X, port security, VLAN isolation
