Grandstream GWN7801P 10-Port Gigabit L2+ Managed PoE+ Switch – 8 PoE+ Ports (120W Budget), 2 SFP Uplinks, VLAN, QoS & Advanced Security

The Grandstream GWN7801P is a high-performance Layer 2+ managed switch designed for small to medium-sized businesses requiring secure, efficient, and scalable networking. It comes with 8 Gigabit Ethernet ports with PoE/PoE+ support (IEEE 802.3af/at), delivering up to 30W per port and a total 120W power budget, ideal for powering Wi-Fi access points, VoIP phones, IP cameras, and IoT devices. Two additional Gigabit SFP uplink ports provide flexible fiber or copper connectivity to ensure seamless network expansion.

Grandstream GWN7801P is engineered with 20 Gbps switching capacity and 10 Gbps non-blocking throughput, the GWN7801P offers wire-speed performance and 14.88 Mpps forwarding rate for smooth traffic handling. Its store-and-forward architecture, 4.1 MB packet buffer, and jumbo frame support up to 15K bytes make it suitable for both standard office traffic and bandwidth-intensive applications.

Grandstream GWN7801P switch supports up to 4,000 VLAN IDs, including port-based, 802.1Q tagging, and voice VLANs, ensuring efficient traffic segmentation. 8 Link Aggregation Groups (LAGs) enhance redundancy and boost throughput. For optimized multimedia and IPTV performance, the switch integrates IGMP snooping, MLD snooping, and MVR.

Grandstream GWN7801P comes with advanced QoS, the GWN7801P ensures reliable application prioritization through priority mapping, traffic shaping, queue scheduling (SP, WRR, WFQ), and bandwidth control. It also offers robust security with ARP inspection, IP source guard, DoS protection, storm control, DHCP snooping, loop prevention, and 802.1X authentication with RADIUS/TACACS+ integration.

Management is flexible with Web UI, CLI (SSH, Telnet, Console), SNMP v1/v2c/v3, RMON, LLDP, Syslog, and integration with GWN.Cloud and GWN Manager for centralized remote monitoring.

Grandstream GWN7801P fanless metal design ensures silent operation, making it perfect for office, retail, and hospitality environments. Compact yet powerful, it supports both desktop and wall-mount installation.

Key Features

• 10 Ports Total – 8 × Gigabit Ethernet PoE/PoE+ (30W per port, 120W budget) + 2 × Gigabit SFP uplinks

• PoE Smart Power – Dynamic per-port PoE/PoE+ allocation with intelligent scheduling

• High Performance – 20 Gbps switching capacity, 10 Gbps non-blocking throughput, 14.88 Mpps forwarding rate

• Jumbo Frame – Supports up to 15K bytes for heavy data transfers

• VLANs – Up to 4,000 VLAN IDs (port-based, 802.1Q tagging, voice VLAN support)

• Link Aggregation – 8 LAGs supported for load balancing and redundancy

• Multicast Optimization – IGMP snooping, MLD snooping, MVR for video streaming and IPTV

• QoS – Advanced traffic prioritization with SP, WRR, WFQ scheduling, bandwidth control, and rate limiting

• Security – ARP inspection, IP source guard, DoS prevention, DHCP snooping, loop protection, storm control, 802.1X with RADIUS/TACACS+

• Management – Web UI, CLI, SNMP, Syslog, LLDP, RMON, GWN.Cloud, and GWN Manager support

• Design – Fanless silent operation, desktop or wall-mount options

• Durability – Metal enclosure, compact size (330 × 175 × 44 mm), weight 2 kg

• Package Contents – Switch, 1.2m AC power cable, ground cable, rack kits, rubber feet, quick install guide

• Warranty – 3 years
